Terex Manlift Specifications
Terex is a Westport, Connecticut company which specializes in producing in manufacturing construction equipment. Machines like aerial lifts, manlifts and boom lifts. These kinds of machinery are designed to facilitate access to areas which are hard to reach, buildings and roofs, large equipment, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also called OSHA refers to a power-driven endless belt. This belt moves only in one direction and includes handholds or platforms or steps which are connected to the unit to be able to transport employees from each floor.
TB85
The TB85 man lift by Terex offers a max working height at 91 feet. The platform's max height reaches 85 feet, while the model's maximum width is 8.5 feet. The TB85 has dimensions measuring 9 feet, 1-inch high and 9 inches wide by 36 feet. This model provides a reach of seventy feet. The TB85 has a boom angle above horizontal measuring 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The maximum height of Terex's TB100 man lift is 106 feet and the platform's maximum height is 100 feet. The TB100 when stowed away, is approximately 8.5 feet wide by 9 feet high by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, while the max working height measures at 116 feet. The model is 8 feet wide x 9 feet, 4 inches high The TB110 offers a horizontal reach of 67 feet and a maximum width of 8 feet. This particular model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
